Standard Spot Ace For Visual Inspection

Model:SPA-10CD / SPA2-10CW / SPA2-10SD / SPA2-10SW / SPA2-10CD


Main Purposes:

  • Discription
  • Catalog


Parameters | ModelSPA2-10CD / SPA2-10CW / SPA2-10SD / SPA2-10SW
ColorCool White(CW,SW), Warm White(CD,SD)
PlacingClamp(CW,CD)  Stand Type(SW,SD)
Lens TypeStandard Type
Lens ModelTKG-3079-650
Intensity ※110,000lx(CD,SD) 30,000lx(CW,SW)
Iradiatable Area ※2φ180mm
Expected LED life ※320,000H (The avarage time until light intensity atenuats to 50% of the initial level)
Filter Size ※4φ30.5mm
Input VoltageDC15V
Power consumption(Max.)12W
DimmingDimmer on the front panel
Cooling methodHeat sink
Operating Conditions0-+40℃, 20%-80%RH (non-moisture)
Net WeightApprox. 0.8kg(excluding AC adapter)
AC adapterAC100-240V 50/60Hz
Out putDC15V 0.8A
※1:WD=200mm, For Reference
※2:WD=200mm, For Reference

※3:For Reference

※4:Ask to person in charge
