| Parameters | Model | LA-100IR-B (AC100-120V), LA-100IR-C (AC200-240V) |
|---|---|
| Input Voltage (AC) | AC100-120V / 200-240V ±10% |
| Frequency | 50/60Hz |
| Power consumption(Max.) | 130W（100WIR Lamp with） |
| Lamp model | JCR12V100W10H/IR (Infrared wavelength) |
| Avarage Life Time ※1 | 1,000H |
| Lighting Method | DC Lighting System |
| Adjustable Voltage | DC3-+12V |
| Adjustable Intensity | 2-100％ |
| Circuit Protector | Auto shut down（Auto recovery） |
| Heat Protector | Auto shut down（recovery by re-start） |
| Cooling method | Cooling fan |
| Filters | Cut visible wavelength thru over 800nm |
| Operating Conditions | 0-+40℃, 20-80％RH（non-moisture） |
| Huse | AC250VT4A（φ5.2×20mm） |
| Remote Function1 | Power ON/OFF, Intensity control(DC0-5V), Over heat protection and Alert |
| Safety Standards | PSE |
| Dimensions | W115×H130×D231mm ※excluding projecting parts |
| Net Weight | Approx. 2.7kg |
| ※1. For Reference | |
